FEATURES

• 1 outlet: 7.9 gpm (30 l/min) – 60 psi
• 2 outlets: 3.7 gpm (14 l/min) – 60 psi
• The best solution to minimize temperature fluctuations
• 3-way diverter with shared port
• NS Option: 3-way diverter with non-shared ports
• Reversible check / non-return valves in case of water supply inversion
• CAR-2661-00 (temperature), CAR-9531-03 (diverter)
• Large depth adjustment range
• 1-3/8″ decorative extension for thick wall or to correct deep rough-ins: order EXT-9520-30-xx
• 1/2″ male NPT or welded copper connections

ECO-FRIENDLY OPTIONS

• NS - Non-shared positions
